Folded Fin Heat Sink

High-Efficiency Folded Fin Heat Sinks for Compact Thermal Solutions

✓ 200–350 W/mK Effective Thermal Conductivity

✓ Aluminum, Copper, or Hybrid Material Options

✓ Ultra-High Surface Area-to-Volume Ratio

✓ ISO 9001 & AS9100 Certified

✓ Prototype to High-Volume Production

Why

Fecision?

Precision At Fecision

Custom CNC Machining & Molded Solutions

As a leading CNC machining and mold manufacturing service provider, we deliver tailored heat sink solutions using advanced materials and manufacturing techniques, including CNC milling, extrusion, die-casting, and bonded fin technology.

Optimized Thermal Performance

CFD-simulated designs for maximum heat dissipation

Durability

Corrosion-resistant finishes for harsh environments

Custom Designs

Collaborate with our engineers for application-specific solutions

Cost Efficiency

Competitive pricing for both low/high-volume orders

Global Compliance

Meet RoHS, REACH, and ISO 9001 standards

Folded Fin Heat Sinks

Folded fin heat sinks are advanced thermal solutions created by folding thin metal sheets into tightly packed, accordion-like fin arrays. This design maximizes surface area while maintaining a compact footprint, making them ideal for applications where space, weight, and heat density are critical constraints.

Our proprietary Manufacturing Process enables micron-level precision in fin folding, achieving 40% higher surface density than stamped alternatives. Prototypes delivered in 5-7 days with thermal validation reports.

Why Choose Folded Fin Designs?

✔️Space Efficiency – Ideal for densely packed electronics (e.g., avionics, servers).

✔️Weight Reduction – 30% lighter than solid machined fins with equivalent performance.

✔️Customizability – Adaptable to curved surfaces or irregular layouts.

Technical Specification Table

Folded Fin Heat Sinks Technical Details

Parameter	Specifications
Material	Aluminum 3003, Copper C110, Custom Alloys
Fin Thickness	0.1–0.5mm
Fold Height	5–50mm
Fin Density	10–40 fins/inch
Surface Finish	Anodized, nickel-plated, epoxy-coated
Thermal Resistance	0.15–1.2°C/W (depending on airflow/material)
Certifications	ISO 9001, AS9100, RoHS, ITAR (optional)
